copper melting furnace
copper melting furnace
Electric induction heating Heat is directly generated inside the material by utilizing the electromagnetic eddy current effect,avoiding the heat conduction loss of traditional resistance furnaces and achieving higher heating efficiency. Intelligent control system Integrate PLC or industrial computer, and adjust power, temperature and melting time in real time through PID algorithm to achieve precise temperature control, effectively save energy and reduce loss.
Digital Power Supply Technology
Utilizing high-frequency IGBT inverter technology, our systems achieve energy conversion efficiencies exceeding 95% through advanced digital control. Compared to traditional line-frequency power supplies, high-frequency technology significantly reduces electromagnetic losses and enables precise power regulation.
Electric Induction Heating
Heat is generated directly within the material via the electromagnetic eddy current effect. This method eliminates the thermal conduction losses associated with traditional resistance furnaces, resulting in significantly higher heating efficiency.
Intelligent Control System
Integrated with PLC or industrial computers, the system utilizes PID algorithms to adjust power, temperature, and melting time in real-time. This ensures precise temperature control, effectively maximizing energy savings and reducing operational losses.
项目Project 型号Model | 容量KG Capacity | 熔化KG/H Melting rate | 配置功率KW Configured power | 最高工作温度℃Max operating temperature | 熔化时间H Melting time |
XCJD-100KG | 100 | 100 | 40 | 1500℃ | 1 |
XCJD-150KG | 150 | 150 | 40 | 1500℃ | 1 |
XCJD-200KG | 200 | 200 | 60 | 1500℃ | 1 |
XCJD-300KG | 300 | 300 | 60 | 1500℃ | 1 |
XCJD-500KG | 500 | 400 | 80 | 1500℃ | 1.15 |
XCJD-800KG | 800 | 600 | 100 | 1500℃ | 1.5 |
XCJD-1000KG | 1000 | 750 | 120 | 1500℃ | 1.5 |
XCJD-1500KG | 1500 | 1100 | 160 | 1500℃ | 1.5 |
XCJD-2000KG | 2000 | 1500 | 160 | 1500℃ | 1.5 |
XCJD-5000KG | 5000 | 3500 | 800 | 1500℃ | 2 |
