aluminum melting furnace
aluminum melting furnace
Digital power supply technology High-frequency inverter power supply(IGBT) is adopted, and the efficient conversion of electrical energy is achieved through digital control(with an efficiency of over 95%).Com- pared with traditional power supplies of industrial frequency, high-frequency power supplies can reduce electromagnetic losses and achieve precise power regulation.
Digital Power Supply Technology
Utilizing high-frequency IGBT inverter technology, our systems achieve energy conversion efficiencies exceeding 95% through advanced digital control. Compared to traditional line-frequency power supplies, high-frequency technology significantly reduces electromagnetic losses and enables precise power regulation.
Electric Induction Heating
Heat is generated directly within the material via the electromagnetic eddy current effect. This method eliminates the thermal conduction losses associated with traditional resistance furnaces, resulting in significantly higher heating efficiency.
Intelligent Control System
Integrated with PLC or industrial computers, the system utilizes PID algorithms to adjust power, temperature, and melting time in real-time. This ensures precise temperature control, effectively maximizing energy savings and reducing operational losses.
项目Project 型号Model | 容量KG Capacity | 熔化率KG/H Melting rate | 配置功率KW Configured power | 最高工作温度℃Max operatingtemperature | 熔化时间H Melting time |
XCJD-100KG | 100 | 100 | 40 | 1200℃ | 1.6 |
XCJD-200KG | 200 | 150 | 40 | 1200℃ | 1.6 |
XCJD-300KG | 300 | 200 | 60 | 1200℃ | 1.6 |
XCJD-400KG | 400 | 250 | 80 | 1200℃ | 1.6 |
XCJD-500KG | 500 | 350 | 120 | 1200℃ | 1.6 |
XCJD-800KG | 800 | 600 | 160 | 1200℃ | 1.6 |
XCJD-1000KG | 1000 | 700 | 200 | 1200℃ | 1.6 |
XCJD-1500KG | 1500 | 1100 | 300 | 1200℃ | 1.6 |
XCJD-2000KC | 2000 | 1500 | 450 | 1200℃ | 1.6 |
